CHASSIS ELECTRICAL EQUIPMENT(CA)

SWITCH - REFLECTORS FOR KAWASAKI Z H2 2021

TOOL

(120) 120CC0614

BOLT-SOCKET,6X14

(120) 120CC0614

BOLT-SOCKET,6X14

(11056) 11056-0238

BRACKET,CLASP

(11057B) 11057-4105

BRACKET,SIDE STAND SWITCH

(11057A) 11057-3840

BRACKET,IGNITION SWITCH

(11057) 11057-1301

BRACKET,REFLECTOR,RH

(21007) 21007-5079

ROTOR,LOCK,TANK CAP

(23062) 23062-1291

BRACKET-COMP,REFLECTOR,LH

(27005) 27005-0711

SWITCH-ASSY-IGNITION

(27008) 27008-0590

KEY-LOCK,BLANK

(27010A) 27010-0934

SWITCH,SIDE STAND

(27010) 27010-0924

SWITCH,STOP

(27016) 27016-1115

LOCK-ASSY,SEAT STRIKER

(27016A) 27016-5389

LOCK-ASSY,SEAT

(27048) 27048-5258

SWITCH-ASSY

(28012) 28012-0045

REFLECTOR-REFLEX,CCC

(28012) 28012-0045

REFLECTOR-REFLEX,CCC

(28012B) 28012-1088

REFLECTOR-REFLEX

(28012A) 28012-1077

REFLECTOR-REFLEX

(28012B) 28012-1088

REFLECTOR-REFLEX

(92019) 92019-008

NUT,LOCK,6MM

(92027) 92027-1045

COLLAR,L=9.6

(92075) 92075-1564

DAMPER

(92075A) 92075-1808

DAMPER,6X10X15

(92075) 92075-1564

DAMPER

(92143) 92143-1408

COLLAR,6.5X9.5X17

(92145) 92145-1908

SPRING

(92153) 92153-1617

BOLT,SOCKET,6X12

(92154A) 92154-1858

BOLT,TORX,6X22

(92154) 92154-0508

BOLT,SOCKET,6X45

(92154B) 92154-2207

BOLT,E TYPE TORX,6X35

(92161) 92161-0117

DAMPER

(92161A) 92161-0118

DAMPER

(92161) 92161-0117

DAMPER

(92200) 92200-0212

WASHER,6X20X1.6

(92210) 92210-0007

NUT,FLANGED,5MM

(92210) 92210-0007

NUT,FLANGED,5MM

(92210) 92210-0007

NUT,FLANGED,5MM

(92210) 92210-0007

NUT,FLANGED,5MM

(92210) 92210-0007

NUT,FLANGED,5MM

	Part number	Description	Qty
# 120	120CC0614	BOLT-SOCKET, 6X14	1,37 €(1,17 £)
# 11056	11056-0238	BRACKET, CLASP	4,12 €(3,53 £)
# 11057	11057-1301	BRACKET, REFLECTOR, RH	5,39 €(4,61 £)
# 11057A	11057-3840	BRACKET, IGNITION SWITCH	68,04 €(58,22 £)
# 11057B	11057-4105	BRACKET, SIDE STAND SWITCH	5,82 €(4,98 £)
# 21007	21007-5079	ROTOR, LOCK, TANK CAP	82,40 €(70,51 £)
# 23062	23062-1291	BRACKET-COMP, REFLECTOR, LH	12,18 €(10,42 £)
# 27005	27005-0711	SWITCH-ASSY-IGNITION	Not available	0,00 €(0,00 £)
# 27008	27008-0590	KEY-LOCK, BLANK	68,63 €(58,73 £)
# 27010	27010-0924	SWITCH, STOP	72,29 €(61,86 £)
# 27010A	27010-0934	SWITCH, SIDE STAND	103,86 €(88,88 £)
# 27016	27016-1115	LOCK-ASSY, SEAT STRIKER	28,85 €(24,69 £)
# 27016A	27016-5389	LOCK-ASSY, SEAT	82,40 €(70,51 £)
# 27048	27048-5258	SWITCH-ASSY	Not available	0,00 €(0,00 £)
# 28012	28012-0045	REFLECTOR-REFLEX, CCC	14,90 €(12,75 £)
# 28012A	28012-1077	REFLECTOR-REFLEX	16,97 €(14,52 £)
# 28012B	28012-1088	REFLECTOR-REFLEX	16,22 €(13,88 £)
# 92019	92019-008	NUT, LOCK, 6MM	3,32 €(2,84 £)
# 92027	92027-1045	COLLAR, L=9.6	3,49 €(2,99 £)
# 92075	92075-1564	DAMPER	3,31 €(2,83 £)
# 92075A	92075-1808	DAMPER, 6X10X15	1,19 €(1,02 £)
# 92143	92143-1408	COLLAR, 6.5X9.5X17	3,00 €(2,57 £)
# 92145	92145-1908	SPRING	7,68 €(6,57 £)
# 92153	92153-1617	BOLT, SOCKET, 6X12	0,80 €(0,68 £)
# 92154	92154-0508	BOLT, SOCKET, 6X45	1,60 €(1,37 £)
# 92154A	92154-1858	BOLT, TORX, 6X22	2,42 €(2,07 £)
# 92154B	92154-2207	BOLT, E TYPE TORX, 6X35	3,31 €(2,83 £)
# 92161	92161-0117	DAMPER	1,86 €(1,59 £)
# 92161A	92161-0118	DAMPER	1,86 €(1,59 £)
# 92200	92200-0212	WASHER, 6X20X1.6	2,12 €(1,81 £)
# 92210	92210-0007	NUT, FLANGED, 5MM	1,68 €(1,44 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of Kawasaki, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
