Front ForkKX500-E4E5 FOR KAWASAKI KX500 1993

Front ForkKX500-E6E7

11009

(11009) 11009-1791

GASKET

11012

(11012) 11012-1692

CAP

13070

(13070) 13070-1204

GUIDE PROTECTOR

13091

(13091) 13091-1651

HOLDER

32085

(32085) 32085-1323

STOPPER

44008

(44008) 44008-1012

PIPE-FORK OUTER

44013

(44013) 44013-1340

PIPE-FORK INNER LH

44013A

(44013A) 44013-1341

PIPE-FORK INNER RH

44018

(44018) 44018-1056

PISTON-FORK INNER PIPE

44022

(44022) 44022-1264

CYLINDER-FORK

44026

(44026) 44026-1486

SPRING-FRONT FORK K=0.39

44026A

(44026A) 44026-1489

SPRING-FRONT FORK K=0.38

44026B

(44026B) 44026-1491

SPRING-FRONT FORK K=0.40

44028

(44028) 44028-1081

GUIDE-FORK SPRING

44028A

(44028A) 44028-1087

GUIDE-FORK SPRING

44029

(44029) 44029-1148

SEAT-FORK SPRING

44037

(44037) 44037-1280

HOLDER-FORK UNDER

44039

(44039) 44039-1212

HOLDER-FORK UPPER

44063

(44063) 44063-1056

HOLDER-FRONT AXLE

44070

(44070) 44070-5129

DAMPER-ASSY FORK

46012

(46012) 46012-1192

HOLDER-HANDLE LWR

46102

(46102) 46102-1303

ROD FORK

46102A

(46102A) 46102-1307

ROD FORK

49116

(49116) 49116-1093

VALVE-ASSY FORK

55020

(55020) 55020-1384

GUARD FORK

92009

(92009) 92009-1568

SCREW

92015

(92015) 922100630

NUT FLANGED 6MM

92015A

(92015A) 922101521

NUT STEERING STEM 22MM

92015B

(92015B) 92015-1805

NUT

92015C

(92015C) 92015-1872

NUT

92019

(92019) 922101184

NUT LOCK 10MM

92022

(92022) 92022-1088

WASHER 10.2X28X2

92022A

(92022A) 92022-1299

WASHER

92022B

(92022B) 92022-1737

WASHER

92022C

(92022C) 92022-1873

WASHER STEERING STEM

92028

(92028) 92028-1581

BUSHING

92033

(92033) 92033-1077

RING-SNAP

92033A

(92033A) 92033-1271

RING-SNAP

92037

(92037) 92037-1627

CLAMP

92049

(92049) 92049-1373

SEAL-OIL

92055

(92055) 670B2022

RING-O FORK

92055A

(92055A) 92055-1333

RING-O FORK AIR TUBE

92055B

(92055B) 670B1503

RING-O

92055C

(92055C) 92055-1442

RING-O

92055D

(92055D) 920551462

RING-O FORK VALVE

92075

(92075) 92075-1776

DAMPER

92093

(92093) 920931342

SEAL FORK OUTER TUBE

92150

(92150) 92150-1270

BOLT 5X35

92150A

(92150A) 921501505

BOLT 6X14

92150B

(92150B) 92150-1516

BOLT FLANGED 8X40

92170

(92170) 92170-1088

CLAMP

	Part number	Description	Qty
# 11009	11009-1791	GASKET	Not available	0,00 €(0,00 £)
# 11012	11012-1692	CAP	3,97 €(3,40 £)
# 13070	13070-1204	GUIDE PROTECTOR	Not available	0,00 €(0,00 £)
# 13091	13091-1651	HOLDER	20,39 €(17,45 £)
# 32085	32085-1323	STOPPER	11,45 €(9,80 £)
# 44008	44008-1012	PIPE-FORK OUTER	Not available	0,00 €(0,00 £)
# 44013	44013-1340	PIPE-FORK INNER LH	Not available	0,00 €(0,00 £)
# 44013A	44013-1341	PIPE-FORK INNER RH	Not available	0,00 €(0,00 £)
# 44018	44018-1056	PISTON-FORK INNER PIPE	20,59 €(17,62 £)
# 44022	44022-1264	CYLINDER-FORK	Not available	0,00 €(0,00 £)
# 44026	44026-1486	SPRING-FRONT FORK K=0.39	Not available	0,00 €(0,00 £)
# 44026A	44026-1489	SPRING-FRONT FORK K=0.38	Not available	0,00 €(0,00 £)
# 44026B	44026-1491	SPRING-FRONT FORK K=0.40	Not available	0,00 €(0,00 £)
# 44028	44028-1081	GUIDE-FORK SPRING	8,82 €(7,55 £)
# 44028A	44028-1087	GUIDE-FORK SPRING	Not available	0,00 €(0,00 £)
# 44029	44029-1148	SEAT-FORK SPRING	Not available	0,00 €(0,00 £)
# 44037	44037-1280	HOLDER-FORK UNDER	Not available	0,00 €(0,00 £)
# 44039	44039-1212	HOLDER-FORK UPPER	Not available	0,00 €(0,00 £)
# 44063	44063-1056	HOLDER-FRONT AXLE	45,01 €(38,52 £)
# 44070	44070-5129	DAMPER-ASSY FORK	Not available	0,00 €(0,00 £)
# 46012	46012-1192	HOLDER-HANDLE LWR	Not available	0,00 €(0,00 £)
# 46102	46102-1303	ROD FORK	Not available	0,00 €(0,00 £)
# 46102A	46102-1307	ROD FORK	Not available	0,00 €(0,00 £)
# 49116	49116-1093	VALVE-ASSY FORK	Not available	0,00 €(0,00 £)
# 55020	55020-1384	GUARD FORK	Not available	0,00 €(0,00 £)
# 92009	92009-1568	SCREW	4,46 €(3,82 £)
# 92015	92015-1078 922100630	NUT FLANGED 6MM	1,37 €(1,17 £)
# 92015A	92015-1653 922101521	NUT STEERING STEM 22MM	12,10 €(10,35 £)
# 92015B	92015-1805	NUT	16,92 €(14,48 £)
# 92015C	92015-1872	NUT	20,39 €(17,45 £)
# 92019	92019-021 922101184	NUT LOCK 10MM	2,12 €(1,81 £)
# 92022	92022-1088	WASHER 10.2X28X2	3,00 €(2,57 £)
# 92022A	92022-1299	WASHER	5,84 €(5,00 £)
# 92022B	92022-1737	WASHER	3,49 €(2,99 £)
# 92022C	92022-1873	WASHER STEERING STEM	5,10 €(4,36 £)
# 92028	92028-1581	BUSHING	15,90 €(13,61 £)
# 92033A	92033-1271	RING-SNAP	4,07 €(3,48 £)
# 92033	92033-1077	RING-SNAP	Not available	0,00 €(0,00 £)
# 92037	92037-1627	CLAMP	20,59 €(17,62 £)
# 92049	92049-1373	SEAL-OIL	19,91 €(17,04 £)
# 92055	92055-1062 670B2022	RING-O FORK	2,88 €(2,46 £)
# 92055A	92055-1333	RING-O FORK AIR TUBE	3,18 €(2,72 £)
# 92055B	92055-1441 670B1503	RING-O	2,53 €(2,16 £)
# 92055C	92055-1442	RING-O	Not available	0,00 €(0,00 £)
# 92055D	92055-1513	RING-O FORK VALVE	Not available	0,00 €(0,00 £)
# 92075	92075-1776	DAMPER	5,14 €(4,40 £)
# 92093	92093-1315 920931342	SEAL FORK OUTER TUBE	13,46 €(11,52 £)
# 92150	92150-1270	BOLT 5X35	3,65 €(3,12 £)
# 92150A	92150-1340 921501505	BOLT 6X14	3,14 €(2,69 £)
# 92150B	92150-1516	BOLT FLANGED 8X40	9,70 €(8,30 £)
# 92170	92170-1088	CLAMP	20,59 €(17,62 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kawasaki. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the Front ForkKX500-E4E5 of your Kawasaki of 1993. Let us know if you have any questions.
